Description

RUCKUS R760 Wi-Fi 6E Tri-Band 4×4:4 Wireless Access Point 10GbE PoE BeamFlex+ Wireless Access Point (901-R760-XX00)

The RUCKUS R760 Wi-Fi 6E Wireless Access Point is a high-performance enterprise access point designed to deliver exceptional speed, capacity, and reliability in demanding wireless environments. Built with Wi-Fi 6E technology, the R760 expands wireless operations into the 6 GHz spectrum while providing advanced features such as 4×4:4 MU-MIMO, OFDMA, BeamFlex+ adaptive antennas, and 10GbE connectivity.

In addition, the R760 is engineered for high-density deployments where thousands of devices require fast and consistent wireless access. As a result, it is an excellent choice for enterprises, universities, healthcare facilities, convention centers, and large public venues.

Specifications Table

Feature	Specification
Model	901-R760-XX00
Product Type	Indoor Wireless Access Point
Wi-Fi Standard	IEEE 802.11a/b/g/n/ac/ax (Wi-Fi 6E)
Frequency Bands	2.4 GHz, 5 GHz, 6 GHz
Radio Configuration	4×4:4 (2.4 GHz), 4×4:4 (5 GHz), 4×4:4 (6 GHz)
Spatial Streams	12 Total Spatial Streams
Wi-Fi Technology	Wi-Fi 6E (802.11ax)
Channel Width	20, 40, 80, 160 MHz
Wi-Fi Features	OFDMA, MU-MIMO, BSS Coloring, TWT
Ethernet Port	1 × 10GbE Multi-Gigabit Ethernet Port
Power Support	PoH, uPoE, 802.3bt PoE
Antenna Technology	BeamFlex+ Adaptive Antennas
Channel Optimization	ChannelFly
Mesh Networking	SmartMesh
Security	WPA2, WPA3, 802.1X, Dynamic PSK
VLAN Support	802.1Q VLAN
Client Capacity	Up to 1,536 Clients
SSIDs Supported	Up to 31 SSIDs per Radio
Management Options	RUCKUS One, SmartZone, ZoneDirector, Unleashed, Standalone
Mounting Options	Ceiling and Wall Mount
Deployment	Indoor Enterprise Environments

Next-Generation Wi-Fi 6E Performance

First, the R760 leverages Wi-Fi 6E technology, which extends Wi-Fi operations into the newly available 6 GHz spectrum. Therefore, organizations gain access to additional channels, reduced interference, and significantly greater wireless capacity.

Key benefits include:

Faster wireless speeds
Lower latency
Reduced congestion
More available spectrum
Better support for modern devices

As a result, users experience smoother connectivity even in busy environments.

Tri-Band Architecture for Maximum Capacity

The R760 operates simultaneously across:

2.4 GHz
5 GHz
6 GHz

This tri-band design increases available bandwidth and allows more devices to connect efficiently.

Benefits include:

Improved network performance
Higher client density support
Better traffic distribution
Enhanced user experience

Therefore, the R760 is well suited for large-scale deployments.

Advanced 4×4:4 Radio Design

The R760 features 4×4:4 radio chains on all three frequency bands, delivering a total of 12 spatial streams.

This architecture provides:

Higher throughput
Improved device performance
Greater network efficiency
Better support for simultaneous users

As a result, organizations can confidently support bandwidth-intensive applications and high user densities.

BeamFlex+ Adaptive Antenna Technology

RUCKUS BeamFlex+ technology dynamically selects the best antenna pattern for each connected device.

Benefits include:

Extended wireless coverage
Reduced interference
Improved signal quality
More reliable connections
Better overall performance

Therefore, users receive strong and consistent wireless connectivity throughout the coverage area.

High-Speed 10GbE Connectivity

To support the throughput demands of Wi-Fi 6E, the R760 includes a 10 Gigabit Ethernet uplink.

Advantages include:

Increased backhaul capacity
Reduced network bottlenecks
Improved wired-to-wireless performance
Future-ready infrastructure

As a result, organizations can fully utilize the performance benefits of the access point.

OFDMA and MU-MIMO Efficiency

In addition, the R760 supports advanced Wi-Fi 6E technologies such as:

OFDMA
MU-MIMO
BSS Coloring
Target Wake Time (TWT)

These technologies improve airtime efficiency and help maintain excellent performance in dense wireless environments.

SmartMesh and ChannelFly Technologies

The R760 incorporates proven RUCKUS optimization technologies.

SmartMesh

Self-forming mesh networking
Self-healing wireless connections
Reduced cabling costs

ChannelFly

Dynamic channel selection
Automatic interference avoidance
Continuous optimization

Together, these technologies help maximize network reliability and performance.

Enterprise Security

Security features include:

Therefore, organizations can protect users, devices, and sensitive data.

Flexible Management Options

The R760 supports multiple deployment and management platforms, including:

RUCKUS One
SmartZone
ZoneDirector
Unleashed
Standalone Mode

As a result, it can scale from small deployments to large enterprise networks.

Key Features

Wi-Fi 6E (802.11ax) technology
Tri-band operation (2.4 GHz, 5 GHz, 6 GHz)
12 total spatial streams
4×4:4 radio design on all bands
10GbE multi-gigabit uplink
BeamFlex+ adaptive antennas
OFDMA and MU-MIMO support
SmartMesh wireless meshing
ChannelFly optimization
Enterprise-grade security
PoH, uPoE, and 802.3bt PoE support
Flexible cloud and controller management

Ideal Use Cases

Summary

The RUCKUS R760 Wi-Fi 6E Tri-Band Wireless Access Point (901-R760-XX00) delivers enterprise-class wireless performance for organizations that need maximum speed, capacity, and reliability. With Wi-Fi 6E technology, tri-band operation, 12 spatial streams, BeamFlex+ adaptive antennas, OFDMA, MU-MIMO, and a 10GbE uplink, it provides a powerful foundation for modern wireless networks. As a result, businesses can support more users, more devices, and more demanding applications while maintaining an exceptional wireless experience.
